Vacuum Formed Unshaped Products

Vacuum Formed Unshaped Products

Product Description:

Description:

Temperature degree: 1260℃ (2300℉), 1400℃ (2550℉), 1430℃(2600℉)

CCEWOOL® classic series vacuum formed unshaped products in a variety of sizes and shapes, including tubular, conical, dome-shaped and box-shaped, most of which can be customized according to the customer's requirements, while some unshaped products will kept in stock for customers, such as casting cap and casing pipe for non-ferrous metal industry, as well as vacuum formed kiln eye for petrochemical industry. Vacuum forming hardener or refractory clay coating can be used to shaped products as a protective layer as per customers requirement

  • Characteristics:

    Low heat capacity;

    Low thermal conductivity;

    Excellent thermal stability;

    Excellent thermal shock resistance;

    Excellent anti-wind corrosion;


    Application:

    Industrial kilns observation hole, thermometer hole;

    Industrial furnace burner brick;

    Industrial furnace door;

    Sump and launder for aluminum products industry;

    Heat insulation for thermal radiation in civil and industrial heating device


  • CCEWOOL® Classic series Vacuum Unshaped Ceramic Fiber

    Item

    1260 STD

    1260 HP

    1400

    1430 HZ

    Classification Temperature

    1050℃

    1100℃

    1200℃

    1350℃

    Density (kg/m3)

    300, 320, 350

    Permanent Linear Shrinkage (%)

    @1000C,24hrs

    2.8

    -

    -

    -

    @1100C,24hrs

    -

    2.8

    2

    -

    @1200C,24hrs

    -

    -

    2.6

    1.9

    @1300C,24hrs

    -

    -

    -

    2.5

    Thermal Conductivity (W/(m·k))

    800C

    0.13

    0.13

    0.12

    0.16

    1000C

    0.19

    0.19

    0.2

    0.2

    Chemical Composition    (%)

    Al2O3

    46

    47-49

    52-55

    39-40

    Al2O3+SiO2

    97

    99

    99

    -

    ZrO2

    -

    -

    -

    15-17

    Al2O3+SiO2+ZrO2

    -

    -

    -

    99

    Fe2O3

    ≤1.0

    0.2

    0.2

    0.2

    Na2O+K2O

    ≤0.5

    0.2

    0.2

    0.2

    Specifications(mm)

    Manufactured based on drawing provided by customer

    Packing

    Carton or Wooded Box
