Product Description:

Description:

Temperature degree: 1200℃.

CCEWOOL® soluble fiber blanket is made from alkaline earth silicate fiber, which is developed from a calcium, magnesium, silicate chemistry to provide thermal insulation. Due to it can be soluble in body’s fluid, it is named of bio soluble fiber. This special fiber is made from a blend of calcium, silica and magnesium which give fiber the ability to support continuous temperatures up to 1200℃.



  • Characteristic:

    Low thermal conductivity

    Low thermal storage

    High tensile strength

    Thermal shock resistance

    Lightweight

    Excellent corrosion resistance


    Application:

    • Reusable insulation for steam and gas turbines

    • High-temperature kiln and furnace insulation

    • Furnace door linings and seals

    • Furnace repairs

    • Boiler and incinerator linings

    • Seals and gaskets

    • Automotive heat shields

    • Appliance insulation

    • Fire protection

    • Duct, stack and flue linings

    • Molten metal splash protection


  • CCEWOOL® Bio Soluble Fiber Blanket

    Classification temperature

    1200 ℃

    Density kg/m3

    96

    128

    160

    Tensile strength Kg/m3, EN1094-1 kPa

    128kg/m3

    75

    Permanent linear change on reheating, %, EN1091-1

    After 24 hours @1000℃

    1.5

    Thermal conductivity, W/m.K  ASTMC-201

    temperature @400℃

    0.1

    @600℃

    0.15

    @800℃

    0.2

    @1000℃

    0.28

    Max short term exposure

    1200 ℃

    Operation temperature

    1000 ℃

    Melting point

    1270 ℃

    Chemical composition(%)

    SiO2

    65-68

    CaO

    27-33

    MgO

    2-7

    Others

    0-1

    Thickness

    Density kg/m3

    Length

    Width

    mm

    96

    128

    160

    mm

    mm

    13

    14640

    610, 1220

    19

    9760

    25

    7320

    38

    4880

    50

    -

    3660

    Note:

    (○) and 1220mm width can be customized according to customer (order amount should not be less than the minimum order quantity)

    (√) for conventional products
