Expandable Ceramic Fiber Paper

Expandable Ceramic Fiber Paper

Product Description:

Temperature degree: 1260℃(2300℉)

CCEWOOL® research series expandable ceramic fiber paper is produced from a mixture of high purity ceramic fiber, natural graphite fine flakes, and organic binders through a fiber washing process. At about 1200 ℉ (649 ℃), the paper expands up to maximum of 400% of its thickness. This feature serves as excellent material for gasket and sealing applications.



  • Characteristics of Product:

    Low thermal capacity

    Low thermal conductivity

    Excellent electrical insulation properties

    Excellent machining performance

    High strength, tear resistance

    High flexibility

    Low shot content


    Application:

    High temperature gasket and seals

    Expansion joints insulation material

    Fire proof

    Seals for industrial furnaces


  • Physical Properties


    Color

    Gray

    Maximum temperature rating ℃

    1260

    Continuous use limit ℃

    1150

    Melting point ℃

    1700

    Chemical Content


    Silica,SiO2

    45-48

    Alumina Oxide,Al2O3

    42

    Carbon,C

    10-15

    Other

    2

    Organic Binder

    5-10

    Tensile Strength


    16-18 pcf.density

    0.5-0.7 Mpa

    Expansion,%increase


    @400℉

    90(from 3mm thickness)

    @1800℉

    420(from 3mm thickness)

    @1800℉

    320(from 3mm thickness)


    Sizes Available

    610/1220mm

    Thickness

    2-5mm
