Ultra Thin Ceramic Fiber Board

Ultra Thin Ceramic Fiber Board

Product Description:

Description:

Temperature degree: 1050℃(1922℉), 1260℃ (2300℉), 1400℃ (2550℉), 1430℃(2600℉)

CCEWOOL® research series ultra thin ceramic fiber board's thickness range is from 5 to 10mm. Manufactured from automatic production line provides it with precise thickness and high compressive strength. It is widely used in electrical appliance and electronic equipment.

  • Characteristics:

    Ultra thin thickness range is 5 -10mm

    Low heat capacity, low thermal conductivity;

    Non-brittle material, good elasticity;

    High compressive strength;

    Excellent wind-erosion resistance, long service life;

    Excellent thermal stability and thermal shock resistance;

    Continuous production, even fiber distribution and stable performance;

    Good sound insulation;

    Good anti-stripping properties;

    Easily molded or cut, easy to install;

    Accurate sizes and good flatness


    Application:

    Electrical appliance and electronic equipment.


  • CCEWOOL® Research series ultra thin ceramic fiber board

    Classification temperature

    1050 (1920℉)

    1260 STD (2300℉)

    1260 HP (2300℉)

    1400 (2550℉)

    1430 HZ (2600℉)

    Operation Temp℃

    950

    1050

    1100

    1200

    1350

    Permanent Linear Change on Heating (%)

    @950C,24hrs

    4

    -

    -

    -

    -

    @1200C,24hrs

    -

    3

    3

    -

    -

    @1300C,24hrs

    -

    -

    -

    3

    -

    @1350C,24hrs

    -

    -

    -

    -

    3

    Thermal Conductivity (w/m.k)

    600℃

    0.13

    -

    -

    -

    -

    800℃

    0.2

    0.13

    0.13

    0.12

    0.16

    1000℃

    -

    0.19

    0.19

    0.2

    0.2

    Rupture Strength (Mpa)

    Thickness≤25mm

    0.5

    0.5

    0.5

    0.5

    0.5

    Thickness>25mm

    0.2

    0.2

    0.2

    0.2

    0.2

    Chemical Composition (%)

    Al2O3

    37

    46

    46-49

    52-55

    39-40

    Al2O3+SiO2

    96

    97

    99

    99

    -

    ZrO2

    -

    -

    -

    -

    15-17

    Al2O3+SiO2+ZrO2

    -

    -

    -

    -

    99

    Fe2O3

    ≤1.0

    ≤0.8

    ≤0.2

    ≤0.2

    ≤0.2

    Na2O+K2O

    ≤0.8

    ≤0.5

    ≤0.2

    ≤0.2

    ≤0.2

    Package

    Carton box or pallet


    CCEWOOL® Research series ultra thin ceramic fiber board

    Thickness (mm)

    5. 10

    Dessity (kg/m3)

    320. 350

    Size (mm)

    1200*1000 or customized size
