PUREWOOL Ceramic Fiber Blanket

PUREWOOL Ceramic Fiber Blanket

Product Description:

Description:

Temperature degree: 1260℃(2300℉),1430℃(2600℉)

CCEWOOL ® PUREWOOL series ceramic fiber blanket is the masterpiece of ceramic fiber products. Adopting purer material-alumina, zirconia, monox, Purewool series ceramic fiber blanket is whiter and the tensile strength could reach 0.08MPa. What’s more, Purewool series ceramic fiber blanket has longer service life and better insulation property due to the improved raw material.

  • Characteristics:

    Excellent chemical stability;

    Excellent thermal stability;

    Excellent tensile strength;

    Low thermal conductivity;

    Low heat capacity;

    Excellent insulation properties;

    Good sound insulation


    Application:

    Industrial furnace wall lining;

    Back lining material;

    Furnace masonry expansion joints, door, roof heat insulation seal;

    High temperature pipe insulation material;

    Module / folded module processing material;

    Fireproof coating.

    Steel industry

    Heat Treating and Annealing Furnaces

    Furnace Door Linings and Seals

    Soaking Pit Covers and Seals

    Furnace Hot Face Repairs

    Reheat Furnaces

    Ladle Covers

    Power generation

    Boiler Insulation

    Boiler Doors

    Reusable Turbine Covers

    Pipe Covering

    Insulation of Commercial Dryers and Covers

    Veneer Over Existing Refractory

    Stress Relieving Furnaces

    Glass Furnace Crown Insulation

    Fire Protection

  • CCEWOOL ® PUREWOOL series ceramic fiber blanket

    Classification Temperature

    1260 PST
       (2300℉)

    1430 PHZ
       (2600℉)

    Operation Temp(℃)

    1100

    1350

    Density (kg/m3)

    96/128/ 160

    Permanent Change on Heating (%), EN1094-1

    After 24 hours           @950℃

    -

    -

    @1000℃

    1.5

    -

    @1100℃

    2

    -

    @1200℃

    2.7

    1

    @1300℃

    5.5

    2

    @1400℃


    3

    Tensile Strength(Kg/m3), EN1094-1 KPa

    Density                       96kg/m3

    60

    60

    128kg/m3

    85

    85

    160kg/m3

    120

    120

    Heat Conductive Co-efficient W/(m·k)(128kg/m3)



    Temperature

    @200℃

    0.07

    0.06


    @400℃

    0.12

    0.1


    @600℃

    0.2

    0.15


    @800℃

    0.3

    0.2


    @1000℃

    0.35

    0.3

    Chemical Composition of ceramic blanket  (%)

    Al2O3

    45-46

    35-38

    Al2O3+SiO2

    ≥99

    -

    ZrO2

    -

    15-17

    Al2O3+SiO2+ZrO2

    -

    ≥99

    Fe2O3

    ≤0.15

    ≤0.2

    Na2O+K2O

    ≤0.2

    ≤0.2

    CaO+MgO

    ≤0.1

    ≤0.1


    Thickness

    Density kg/m3

    Length

    Width

    mm

    96

    128

    160

    mm

    mm

    6

    -

    7200

    610, 1220

    13

    14640

    19

    9760

    25

    7320

    38

    4880

    50

    -

    3660

    Note:

    (○) and 1220mm width can be customized according to customer (order amount should not be less than the minimum order quantity)

    (√) for conventional products
